HPDB 100 Pin SCSI Connector
PCM Cable Co., Ltd. is one of the leading HPDB 100 Pin SCSI Connector manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
The key value of PCM-TAT-0013 lies in providing 100 individual contact positions through one compact HPDB100 interface, creating a centralized physical I/O point for high-channel-count industrial equipment.
DAQ cards, digital I/O modules, motion controllers, and ATE systems often handle numerous trigger, encoder, digital I/O, status, and auxiliary control circuits simultaneously. Using multiple low-pin-count connectors would increase panel space and wiring complexity.
The 1.27mm high-density HPDB100 layout consolidates these circuits into a single interface for efficient interconnection between control cards, test hosts, and terminal boards.
A 100-position connector concentrates a large number of solder joints and conductors behind the interface, making mechanical protection especially important. PCM-TAT-0013 uses an assembled zinc alloy backshell to enclose the rear solder termination area within a rigid metallic structure.
When incorporated into a properly designed shielded cable assembly, the metal housing can also form part of the shielding path for electrically noisy industrial cabinets, servo systems, and test platforms.
Proper cable clamping and strain relief prevent the combined weight and pulling force of the conductors from being transferred directly to the solder joints.
Products Specification
| Product Name | HPDB 100-Pin Male Connector |
| Drawing Number | PCM-TAT-0013 |
| Connector Type | HPDB High-Density Male |
| Number of Pins | 100 pins |
| Terminal Arrangement | Dual-row layout, 50 pins per row |
| Enclosure Type | Metal shielded assembly shell |
| Locking Method | Dual-screw locking |
| Rated Current | 1.0A |
| Working temperature | -55°C to +85°C |
Products Display
Product Features
0.050-Inch (1.27mm) Hyper-Fine Pin Matrix
Formed tightly around the standard 1.27mm pin centerline metric, smoothly fitting 100 physical copper pins within a concentrated faceplate boundary.
Multi-Piece Split Impact-Resistant Armor
Modular-assembled thick zinc alloy armor provides rock-solid physical casing, entirely absorbing violent field crushing or heavy hardware impacts.
Elevated Flame-Retardant Insulator Barriers
Miniature physical partition walls implemented inside the core scale up the surface electrical creeping distance between dense pins for voltage defense.
Bilateral Captive Asymmetrical Jackscrews
Symmetry-balanced stainless steel captive screws on the flanks remain securely trapped inside the shell frame even if vibrating loose in dark server racks.
Core Application Scenarios
Large-Scale Multi-Axis Motion Control Systems
Suitable for advanced CNC machines, wafer-handling robots, precision positioning platforms, and multi-axis automation equipment. The HPDB100 interface provides a high-density 100-position connection between motion-control boards, distributed servo drives, encoder interface boards, and I/O modules. It consolidates encoder, limit, home, trigger, status, and control circuits into one harness, reducing connector congestion while simplifying system commissioning, signal tracing, and maintenance.
Semiconductor IC Burn-in & ATE Testing
Designed for IC burn-in systems, ATE platforms, wafer probe stations, wafer sorters, and semiconductor functional validation equipment. The HPDB100 interface provides high-density connectivity among test controllers, interface boards, load boards, fixtures, and acquisition modules. Multiple measurement, trigger, digital I/O, status, and control circuits can be consolidated into one 100-pin interface, simplifying pin-to-pin management, fixture replacement, channel troubleshooting, and adaptation to different semiconductor test programs.
Core Performance Advantages
SCSI-5 Ultra-320 Bus Full-Rate Synchronicity
Perfectly handles high-frequency parallel SCSI-5 control scripts, yielding true zero-skew synchronization across dozens of closed-loop encoders.
Micro-Ohm Elastic Contact Low Thermal Loss
Massive gold interface pairing with beryllium copper springs generates minimal heat even during 100-channel full-load all-power executions.
360° Continuous Faraday Low-Impedance Shield
The alloy armor creates a seamless low-resistance grounding loop with zero microwave leakage gaps, fully isolating external RF pulses.
Full-Time Zero-Dropout Severe Vibration Insurance
Distinct ribbon-style wiping contact mechanisms ensure the Bit Error Rate (BER) stays locked at absolute zero under heavy multi-G resonance.
Frequently Asked Questions
Q1: 100 pins are too densely packed; what tips does Premier Cable's soldered male connector havefor preventing adjacent short circuits during assembly and wiring?
A1 : This is indeed the biggest process challenge in ultra-high density mini D-sub wireharnesses. To address this pain point, our HPDB100-pin male plug features a three-dimensionalstepped solder cup with four vertically arranged rows and staggered depths behind the pin header.This arrangement physically pulls apart the previously crowded operational space. We stronglyrecommend when welding: 1 choose the diameter of 0.4 mm or less car gauge fine wire; Thesoldering iron adopts micro knife head, the temperature is controlled at 350 C-380 Cfor rapid spotwelding; 3 Welding in reverse order from the innermost row to the outermost row. Because the pinsfixed insulators use top-notch high-heat resistant LCP plastics, you don't have to worry aboutmelting the plastic or loosening or tilting the pins due to prolonged iron holding, making themideal for high-reliability automated test kit wiring ( Automated test fixture wiring) customization.
Q2: Howisthe thickness of the zinc alloy housing of the product? How doest bite and fix such athick and heawy cable harness with 100 cores
A2: Our 100-pin standard SCS cable connector is equipped with a newly developed thickened heavy duty assembledalloy rear case.The encosure is modularized by two parts, which can be easily assembled even when the roots of the wireafter the internal end are thick. At its core, a heavy metal beam dip that can be adjusted in multiple stages and in twodirections is integrated at the tail opening of the casing. It specifically widened and deepened the outer geometry of the 100-core fully shielded ultra-thick shielded wire. After tightening, the metal damp can firmly crush or freeze the outer coating witha grip force of more than 15ON, completely eliminating all pulling pull forces outside the shell, and absolutely not allowingeven a trace of external force to be transmitted to the tiny solder points inside.
Products Drawing
