SDR 26 Pin Camera Link Connector
PCM Cable Co., Ltd. is one of the leading SDR 26 Pin Camera Link Connector manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
PCM-TAT-0006 is an SDR 26 Pin Mini Camera Link Connector developed by Premier Cable for professional machine vision equipment. The Shrink Delta Ribbon interface combines 26 high-density contacts with a fine 0.8mm pitch, minimizing connector footprint while providing the connectivity required by industrial imaging systems.
The 0.8mm SDR 26-pin format is widely associated with Mini Camera Link applications for industrial cameras and frame grabbers. Compared with the larger 1.27mm-pitch MDR 26-pin Camera Link interface, SDR offers a substantially more compact connection for miniature cameras, embedded vision modules, and space-constrained imaging equipment.
Its solder-type termination makes PCM-TAT-0006 suitable for custom machine vision cable assemblies and OEM Camera Link interconnects where controlled wiring, shielding, and mechanical integration are required.
Core Edge
PCM-TAT-0006 integrates 26-pin high-density Mini Camera Link connectivity into a compact 0.8mm-pitch SDR architecture. It establishes a direct high-speed image and control signal path between industrial cameras and frame grabbers while occupying less space than conventional MDR 26-pin interfaces. This compact design is ideal for embedded vision modules, miniature cameras, and multi-camera systems where PCB area, optical components, and thermal layout space are limited.
Stable Connectivity
Designed for AOI equipment, high-speed linear stages, industrial robots, and continuously operating automation lines, PCM-TAT-0006 uses secure mechanical retention to maintain stable SDR 26-pin mating under vibration. Reliable contact construction helps minimize connector displacement and intermittent contact caused by cable movement or prolonged operation, reducing the risk of image flicker, acquisition errors, and unexpected link interruptions in 24/7 machine vision systems.
Installation Demands
PCM-TAT-0006 features a solder-type termination designed for professional cable manufacturers, machine vision equipment builders, and OEM production. Its fine 0.8mm-pitch SDR 26-pin layout requires accurate Camera Link pin assignment, controlled solder volume and temperature, minimal differential-pair untwisting, and proper shield termination. After soldering, compatible insulation, strain relief, and housing components can protect the termination for compact industrial cameras and high-density equipment installations.
Products Specification
| Product Name |
SDR 26-Pin High Density Industrial Connector |
| Drawing No. | PCM-TAT-0006 |
| Locking screws | M2 × 2PCS |
| Overall connector width | 24.20 ±0.35mm |
| Main body width | 19.20 ±0.35mm |
| Total contacts | 26 pins |
| Current Rating | 0.5 AMPS |
|
Operating Temperature |
-55°C to +85°C |
Products Display
Product Features
Ultra-Dense 0.8mm Pitch Solder Pot Matrix
Features a miniature pin centerline layout with ultra-compact solder cups, shrinking footprints vs. legacy MDR components for tight device backplanes.
Tiered Staggered Solder Terminal Geometry
Unique staggers on wire-wrap terminals maximize workspace for precision soldering irons, wiping out solder-bridging shorts between adjacent lines.
Ruggedized Die-Cast Zinc-Alloy Shielding Hood
Equipped with a total metallic shell assembled by high-torque locking hardware, delivering deep anti-tug strain-relief for fragile internal wires.
Dual Interlocking Thumb-Screw Mechanisms
Integrates high-precision threadlocks on both flanks, executing firm mechanical seating into camera mounts that never backs out.
Core Application Scenarios
AOI & Semiconductor Wafer Inspection
Ideal for PCB AOI, semiconductor wafer inspection, chip packaging inspection, and precision electronics manufacturing. The SDR 26-pin Mini Camera Link interface connects high-speed line-scan or area-scan industrial cameras with frame grabbers while minimizing installation space. It provides a reliable imaging link for detecting solder defects, circuit anomalies, wafer scratches, particle contamination, and dimensional deviations in high-speed precision inspection lines.
Precision Robotic Guidance & Smart Logistics
Designed for multi-axis industrial robots, automated sorting systems, machine loading equipment, and smart logistics platforms. The compact 0.8mm SDR 26-pin interface connects robot-mounted industrial cameras to frame grabbers for continuous image acquisition, supporting object positioning, contour recognition, pose correction, precision picking, assembly guidance, and high-speed automated sorting.
Core Performance Advantages
Flawless LVDS Differential Signal Transfer
Internal conductors are optimized for high-frequency weak currents, backing multi-gigabit throughput to guarantee zero frame drops during fast captures.
Multi-Channel PoCL Co-Site Current Carriage
Conductors deliver exceptional ultra-low contact resistance to support Power over Camera Link grids, fusing high-speed data and DC feeds.
360° Faraday Cage Electromagnetic Noise Block
Forms an airtight electromagnetic cage once mated with shielded wire-wraps, slashing Bit Error Rates (BER) in electronically chaotic factories.
Frequently Asked Questions
Q1: The 0.8mm pitch is extremely narrow. Is manual soldering tough for wire factories? How can we prevent bridges?
A1: While 0.8mm requires care, our PCM-TAT-0006 features a tiered staggered solder terminal geometry that distances adjacent cups in physical dimensions. Using sub-0.5mm wire strands and micro soldering tips along with individual heat-shrink tubes makes clean, zero-bridge connections easy.
Q2: Is this SDR 26-pin connector fully compatible with the PoCL standard? Are there strict pinouts during wiring?
A2: Yes, it is built to handle the higher currents of PoCL grids. As a passive node, the pin load-capacities exceed standard specs. As long as your cable shield and soldering scheme follow official Camera Link assignments (allocating specific pins to 12V and GND), unified data and power tracking work safely.
Products Drawing
