Mega-Fit Power and Signal Cable Assembly

The Mega-Fit power and signal cable assembly is a high-performance cable solution designed for applications that require high current carrying and reliable connections. The assembly features a double-row Mega-Fit connector with 4 circuits to provide robust power and signal transmission in space-constrained environments. Each connector is rated up to 30A and 600V, making it ideal for high-current applications such as telecommunications equipment, industrial automation systems, and data centers. Whether used in power distribution units (PDUs), server racks, or communications and networking equipment, this cable assembly ensures a secure and stable connection. Its compact design and anti-misinsertion mechanism further enhance user convenience during installation and maintenance. Choose the Mega-Fit to Mega-Fit cable assembly to provide an efficient and reliable cable assembly solution for your project.





Product name	Cable assembly Mega-Fit to Mega-Fit 4 positions 5.70mm pitch
Compatible with	Molex 45136 series
Connector type	Mega-Fit connector (dual row)
Cable type	Discrete wire assembly, high-power assembly
Circuits	4 (2, 4, 6, 8, 10, 12 are available)
Number of Rows	2
Pitch	5.7mm
Maximum current	30A per circuit
Maximum voltage	600V
Wire gauge	10 - 16AWG
Cable length	15cm, 30cm, 1m, or customized
Operating temperature	-40°C to 150°C





• High current carrying capacity: Each contact can support up to 30A of current, suitable for power-intensive applications.



• Compact design: The dual-row layout saves space while providing high-density connections.



• Durability: The use of high-quality materials and design ensures reliability and durability in harsh environments.



• Convenient installation: Easy to connect and disassemble, saving maintenance time.



• Error-proof design: The connector adopts an anti-misconnection design to ensure correct connection and avoid wrong connection.







• Home appliances: Mega-fit cable assembly can be used in washing machines, dryers, heaters, and air conditioners to ensure efficient power transmission.



• Telecommunications/Networking: Mega-Fit power and signal cable assembly is suitable for hubs, servers, and power and distribution systems to provide reliable connections.



• Industrial: Mega-Fit Off-the-Shelf OTS cable assemblies are suitable for machinery and heavy equipment, lighting, and automation systems to meet high load requirements.



• Commercial vehicles: The Mega-Fit power cable can be used for unsealed electronic control modules and power converters to ensure a safe and stable power supply.





Premier Cable is a professional cable assemblies and wire harnesses manufacturer committed to providing customers with high-quality cable assembly solutions. The wire harnesses we produce include various types of cable assemblies such as Mega-Fit, Nano-Fit, Micro-Fit, Mini-Fit, and JST, which are widely used in various electronic devices and industrial applications. We use many well-known big-brand connectors such as Molex, AMP, Tyco, JST, TE Connectivity, Amphenol, Hirose Electric, and Phoenix Contact to ensure that our products have excellent performance and reliability. Whether it is a custom solution or a standard product, Premier Cable can meet the different needs of customers and help your project succeed.
