HSD Panel Mount Extension Cable

PCM Cable Co., Ltd. is one of the leading hsd panel mount extension cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.

In automotive electronics and high-speed data transmission applications, HSD connectors are typically soldered directly onto the PCB. While this presents no issues during the structural design phase, it becomes a complication during the final assembly or maintenance stages-specifically, the connector cannot be conveniently routed to the device's front panel.

This newly developed HSD panel-mount male-to-female extension cable from Premier Cable offers a precise solution to address this practical challenge.

By utilizing a panel-mount HSD male connector (Z-Code) at one end, it extends the interface-originally situated on the PCB-to the exterior of the device; simultaneously, an HSD female connector at the other end connects to the internal board-side interface, thereby establishing a stable and reliable extension link.

Simply put, it resolves the following issue:
The inability to configure an HSD interface as a detachable, panel-mountable port.

Panel Mount HSD Male Connector (16mm Cutout)
Features a 16mm panel cutout size, allowing for direct mounting onto chassis or equipment enclosures.

HSD Z Code Standard
Compliant with high-speed data transmission standards, suitable for LVDS and automotive communication applications.

Male-to-Female Extension Design
Internally connects to a male PCB header while providing a panel-side interface externally.

20cm Compact Cable Length
Ideal for short-distance extensions within a chassis enclosure.

High-Quality LVDS Cable (Leoni Dacar 535)
Ensures stable transmission performance, suitable for high-speed signal applications.

In numerous projects, we have repeatedly encountered a recurring set of issues:

• The HSD interface located on the PCB cannot be directly utilized as an external port.
• There is no standard panel-mount HSD connector available.
• During maintenance or testing, the device enclosure must be disassembled in order to establish a connection.

This HSD panel mount cable is not merely "just another option," but rather a structural-level solution:

1. It "transforms" an internal interface into an external one.
2. While simultaneously preserving the original high-speed transmission performance.

From the perspective of overall system design, this approach is often far more efficient than redesigning the PCB.

• Automotive camera systems
• LVDS signal transmission
• Infotainment and display modules
• ADAS / sensor systems
• Embedded control units
• Test & validation setups
