HSD Quad To 4 X SMA Automotive Cable Assembly

This automotive wire harness is designed and manufactured by Premier Cable Factory, which has multiple automated production lines and strict quality control system, and has long been providing automotive high-speed connection cable solutions for European and American customers. We provide OEM / ODM customization services, and can quickly make samples and mass production according to drawings, samples or application requirements.



The HSD Quad to 4 x SMA Automotive Cable Assembly is designed for applications that require simultaneous transmission of high-speed differential signals and RF signals. It is widely used in high-frequency data communication systems such as camera systems, millimeter-wave radars, and test platforms in the automotive industry.





Product name	4-in-1 HSD to SMA cable for automotive & RF testing
DWG No.	PCM-ZC-0057
Connector 1	1x HSD connector, female
Connector 2	4 x SMA connector, male
Cable length	50cm or customized
Cable	RG316 double shielding
Cable type	50 Ohm coaxial cable
Data rate	Up to 20 GHz
Shielding	360˚ fully die-cast shielded connector design
Construction	Fully shielded coaxial cable
Applications	ADAS, infotainment systems, in-vehicle navigation, and vehicle telematics systems







• Connect the vehicle-mounted GMSL/FPD-Link camera system to the high-frequency signal acquisition terminal



• Signal interface between the autonomous driving platform and the test equipment



• NVIDIA Jetson or other AI computing platform high-speed signal interface test



• Integration solution of vehicle-mounted radar, camera and SMA RF module



• Multi-channel high-speed data or RF signal splitting/acquisition/interference injection test



• High-speed connection line in HIL/VIL simulation test platform
