Premier Cable PCM-0985 is an XT60 Power Distribution Box 6 Port designed for multi-device DC power connection applications. Featuring a single-input and six-output structure, it expands one XT60 power source into multiple XT60 connection points for centralized equipment and battery management.
Unlike traditional XT60 splitter cables, this Power Distribution Box uses a fixed integrated structure to keep six output ports aligned and organized, reducing cable clutter and loose connection points. The straight rail-style layout is ideal for charging benches, battery test fixtures, drone service stations, and portable DC power systems.
By providing centralized XT60 power distribution, PCM-0985 improves connection efficiency and creates a cleaner, more reliable expansion solution for applications requiring multiple XT60 interfaces.
Installation Requirements
The High-current heavy lifting drone PDB features a compact hexagonal design with aluminum alloy mounting flanges, allowing direct installation on drone frames, equipment structures, or control boxes without additional brackets. The six XT60 ports are arranged for easy access, enabling fast connection and maintenance in space-limited environments.
Manufacturing Process
PCM-0985 uses a high-strength aluminum alloy housing and precision manufacturing process. The internal copper conductive structure provides stable and balanced current paths between XT60 ports. With vibration-resistant insulation potting, it improves impact protection, moisture resistance, and dust protection for outdoor drones, mobile power systems, and industrial equipment.
Service Life
The 6 Port XT60 Power Distribution Box features durable XT60 connectors and reinforced metal construction for long-term high-current operation and repeated connections. The anodized aluminum housing provides resistance against oxidation, moisture, and outdoor conditions. Each unit undergoes electrical and reliability testing to ensure dependable service life.
Products Specification
| Product Name | XT60 1-to-6 Power Distribution Hub |
| Drawing No. | PCM-0985 |
| Configuration | 1 × XT60 Male Input to 6 × XT60 Female Outputs |
| P1 Input | XT60 Male Plug |
| P2–P7 Outputs | XT60 Female Socket |
| Main Body Length | 118 mm |
| Main Body Height | 20.5 mm |
Products Display
Product Features
Symmetrical Hexagonal Busbar Network
Outfitted with 6 genuine XT30/XT60 interfaces mapped in a centripetal hexagonal footprint around the primary trunk entry, this balanced geometry guarantees unified electrical resistance across all sub-loops.
Segmented Aluminum Explosion-Proof Casing
The box chassis is forged with rigid aluminum alloy metal segments. This structural metallic shield provides elite resistance against vehicular crush while integrating internal isolated chambers to suppress arcing.
Widened Mounting Flanges with Inset Ports
The profile is finished with expanded side mounting lips featuring deep countersunk bolt holes. Operators can screw the brick flush against metallic utility vehicle walls or aircraft plates to resist heavy displacement.
Monoblock Solid-Copper Central Busbar
Leaving legacy circuit boards behind, the interior utilizing a monoblock, stamped solid-copper disk to jump common polarities. This expands cross-sectional metallic mass to handle high continuous continuous currents.
Core Application Scenarios
Field Telemetry Base Stations & Mobile Power Distribution
Serving as an Industrial 6-port DC power bar, this XT60 Power Distribution Box is designed for field research camps, mobile communication stations, and remote telemetry bases. It expands centralized DC power into six independent output channels to supply satellite communication units, wireless relay equipment, vehicle-mounted base stations, and monitoring systems. The centralized distribution structure reduces wiring complexity, improves deployment efficiency, and supports reliable long-term operation in remote environments.
High-Capacity Automated Product Burn-In Racks
Used as a 6-port high-current battery splitter trunk, this distribution solution is ideal for motor manufacturing, battery PACK testing, and electronic product burn-in systems. It expands one high-power DC source into six balanced power channels, allowing multiple devices under test (DUTs) to operate simultaneously under continuous load conditions. The organized distribution structure improves test rack efficiency, simplifies power wiring, and provides stable energy delivery for industrial reliability validation.
Frequently Asked Questions
Q1: What is the maximum continuous current rating, and what is the maximum input DC voltage threshold?
A1: The heavy monoblock central copper disk network is fully rated to handle a collective continuous input current of 120A to 150A (with a transient spike threshold of 200A under optimized cooling airflow). For operational input voltage, it accommodates low-voltage DC lines up to 60V, making it fully compatible with 12V, 24V, 36V, and high-voltage 48V (approx. 12S to 14S LiPo aircraft flight packs) primary power trunks.
Q2: Although the metallic enclosure is rugged, will the aluminum shell burn users under steady 100A draws?
A2: There is absolutely no risk of localized hot-spot burning. Because the core implements a thick solid-copper matrix as the primary hub, the total internal micro-ohm trace resistance is nominal, slicing heat output. Furthermore, leveraging the active thermal equalization traits of the aluminum casing, any small ambient heat is rapidly and uniformly dispersed across the cooling fins into surrounding air layers, keeping the surface safe and slightly warm to the touch.
Q3: Does this distribution module embed internal filtering capacitors or fuses inside? What if a sub-motor jams?
A3: To capture the ultimate MTBF across high-shock field zones, this module removes fragile electrolytic filtering capacitors or sacrificial fuses that could dry up or falsely trip under high ambient heat, operating as a passive high-conductivity hub built to deliver max mechanical uptime. We advise installing an appropriately rated master breaker or inline slow-blow fuse on your primary input feed wire to safeguard the collective network if a terminal short occurs.
