Hirose HR25 To Molex Micro-Fit 3.0 I/O Cable
PCM Cable Co., Ltd. is one of the leading hirose hr25 to molex micro-fit 3.0 i/o cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
Built for Compact I/O Interfacing
The PCM-S-0705 HR25 to Micro-Fit 3.0 I/O Cable is designed for signal and control interconnections in compact industrial and embedded systems where space and routing flexibility are critical.
One end of the cable features a right-angle HR25-style 8-pin circular plug, allowing tight clearance installations and reduced strain at the connector. The opposite end is terminated with an 8-pin Micro-Fit 3.0 female connector, commonly used on control boards, I/O modules, and embedded electronics.
Specifications
| Product Name | I/O Cable Hirose HR25-7TP-8S To Molex Micro-Fit 3.0 Cable |
| DWG No. | PCM-S-0705 |
| Connector A | HR25-7TP-8S (Equal), 8-Pin, Right Angle (Female) |
| Connector B | Molex Micro-Fit 3.0, 8-Pin Female |
| Number of Positions | 8 |
| Cable Type | Multi-core I/O Cable |
| Cable Length | 0.7m or customized |
| Wire Gauge | 24 AWG |
| Conductor Count | 8 Cores |
| Cable Diameter | 6.0 mm |
| Jacket Material | PVC |
| Connector Orientation | 90° Right Angle at Connector A |
| Application Type | Signal & Low-Voltage Control I/O |
| Installation Environment | Industrial / Embedded Systems |
| Customization | Length, pinout, labeling available |
| Manufacturing Type | Factory-assembled cable |
| Compliance | REACH / RoHS compliant |
Integration Notes for Engineers
- Right-angle connector helps reduce bend radius and connector stress
- Micro-Fit 3.0 interface supports secure locking in vibration-prone environments
- Suitable for low-voltage signal and control applications
- Ideal for OEM assemblies where custom harnesses are required
- Custom pin assignments and cable lengths can be produced based on system requirements.
Typical Use Cases
- Industrial controllers and I/O modules
- Embedded systems and custom electronics
- Robotics and automation equipment
- Test fixtures and diagnostic interfaces
- Compact machinery with limited connector clearance
FAQ
Q1: Is this Hirose HR25 to Molex Micro-Fit 3.0 cable intended for power or signal use?
A1: It is typically used for signal and low-voltage control I/O, depending on pin assignment.
Q2: Can the cable length be customized?
A2: Yes. Length, pinout, and labeling can be customized for OEM projects.
Q3: Is the Micro-Fit connector locked?
A3: Yes. The Micro-Fit 3.0 interface provides a positive locking mechanism.
Q4: Do you support other HR25 pin counts?
A4: Yes. Other pin counts and connector styles are available upon request.
About Us
Premier Cable is a direct cable and wire harness manufacturer, specializing in industrial I/O cables, circular connector assemblies, and custom interconnect solutions.
Our capabilities include:
- Custom pinout and harness design
- Small-batch prototyping and volume production
- Consistent assembly and electrical testing
- OEM and private-label support
