4 pin Micro-Fit up angle down angle power harness vertical exit cable assembly
90-degree up-angle Mini-Fit Jr. 4-pin power and signal cable assembly
Down-angle Micro-Fit 3.0 Molex OTS cable assembly for compact routing
Custom Up & Down Angle 4-Pin Micro-Fit, Mini-Fit & Mega-Fit Molex OTS Cable Harness Solutions
4 pin Micro-Fit vertical exit angled harness for control panel compact electrical cabinet internal power wiring
Micro-Fit 3.0 90° Up, Down Angle Cable Assemblies (3.0mm pitch)
4 pin Micro-Fit down angle vertical exit cable assembly
micro-fit 3.0 vertical exit power harness with molded connectors
Custom Up & Down Angle 4-Pin Micro-Fit, Mini-Fit & Mega-Fit Molex OTS Cable Harness Solutions
PCM Cable Co., Ltd. is one of the leading custom up & down angle 4-pin micro-fit, mini-fit & mega-fit molex ots cable harness solutions manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
Our custom Up Angle and Down Angle 4-pin cable harnesses support the full Molex Fit series, including Micro-Fit, Mini-Fit, and Mega-Fit, offering reliable power and signal transmission in compact routing environments.
Angled connectors provide a vertical cable exit that simplifies wiring inside control boxes, power modules, server chassis, robotics, and automotive ECUs. Ideal for tight-space installations where traditional straight connectors are difficult to route.
Specifications
| Product Name | 4-Pin Vertical Exit Cable Assemblies with Up Angle & Down Angle Micro-Fit, Mini-Fit, and Mega-Fit Connectors |
| DWG No. | Up angle (PCM-HD-0214); Down angle (PCM-HD-0215) |
| Pin Count | 4 Pins |
| Angle Types | 90° Up Angle / 90° Down Angle |
| Wire Gauge | 18–30 AWG |
| Cable Type | Overmolded multi-core assembly |
| Jacket Material | PVC / TPE / UL-certified cable |
| Operating Temperature | −20°C to +85°C |
| Connector Orientation | Vertical cable exit |
| Compliance | RoHS / REACH |
Features
- Up Angle & Down Angle orientation for flexible cable routing
- Compatible with Micro-Fit / Mini-Fit / Mega-Fit 4-pin interfaces
- Supports 18–30AWG wire gauges
- Customizable lengths, jackets, UL options, pinouts, locking types
- Durable molded strain-relief for stable mating and vibration resistance
- Suitable for power distribution, control signals, batteries, telecom equipment, industrial automation
Applications
- Industrial controllers & automation devices
- Telecom power units & 5G modules
- Server power trays & storage systems
- Automotive electronics / battery systems
- Robotics, AGV, and compact embedded designs
Why Choose Our Factory
- Professional OEM/ODM harness manufacturing
- Support for low-volume and mass production
- Fast tooling for custom angle molds
- 100% electrical test: continuity, polarity, pull-force
- Competitive pricing and export-ready packaging
