IP67 Left Angle FAKRA Extension Cable
PCM Cable Co., Ltd. is one of the leading ip67 left angle fakra extension cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
The key advantage of Premier Cable PCM-ZC-0179 is not simply its 90-degree FAKRA construction, but its defined cable-left routing direction. The Rosenberger 59K2LK-102A4-Z waterproof FAKRA jack turns the coax toward the left immediately after mating, reducing rear-clearance requirements behind camera controllers, antenna modules, TCUs and displays while supporting cleaner harness routing.
PCM-ZC-0179 uses LEONI DACAR 462 automotive coax to establish a shielded 50Ω signal path, with the finished assembly specified for DC–3GHz operation and VSWR ≤1.80. The 59K2LK-102A4-Z belongs to Rosenberger's waterproof FAKRA family and supports a watertight mated connection under the specified waterproof mating conditions according to LV214.
Before selecting PCM-ZC-0179, verify that its cable-left orientation matches the intended equipment routing path. The P1 side uses a 59K2LK-102A4-Z left-exit FAKRA jack, while P2 uses a 59Z176-C01-Z straight plug, both with Z coding. Proper bend radius should be maintained, and the cable should not be forced to reverse direction immediately behind the angled connector.
Products Specification
| Product Type | IP67 Waterproof FAKRA Z Code Coaxial Cable |
| Drawing Number | PCM-ZC-0179-X |
| Connection Structure | FAKRA Jack Z Code to FAKRA Plug Z Code |
| Cable | LEONI DACAR 462 Coaxial Cable |
| Length | 150 +5 mm ; 2000mm |
| Naterproof Rating | IP67 |
| P1 Connector | Rosenberger 59K2LK-102A4-Z ;FAKRA Jack Z Code |
| P2 Connector | Rosenberger 59Z176-C01-Z ; FAKRA Plug Z Code |
Products Display
Product Features
Directional Left Cable Exit
The 59K2LK-102A4-Z left-exit geometry redirects the coax close to the module, supporting installations with restricted rear clearance.
Z Code Interface
The FAKRA Z Code interface supports vehicle modules, extension harnesses and RF equipment designed around the universal Z-coded connection format.
Jack-to-Plug Architecture
Its FAKRA jack-to-plug architecture provides a practical extension between opposite mating interfaces while maintaining Z Code connectivity.
Compact Short Harness
The standard 150±5mm short-harness layout minimizes excess cable inside equipment and supports compact point-to-point RF connections.
Core Application Scenarios
In-Vehicle Infotainment Systems
Designed for RF connections in in-vehicle infotainment systems, supporting stable transmission between antennas, head units, and communication modules while optimizing cable routing in space-constrained installations.
Automotive Electronic Control Modules
Suitable for connecting automotive electronic control modules with antennas, communication units, and RF devices, featuring IP67 protection and a left-angle cable exit for compact module installations.
Core Performance Advantages
Controlled 50Ω Impedance
LEONI DACAR 462 automotive coax provides a controlled 50Ω transmission path, helping limit RF degradation caused by impedance discontinuities.
IP67 Interface Protection
The IP67 waterproof FAKRA interface provides added protection for automotive connections exposed to moisture, dust and demanding operating environments.
DC–3GHz Operating Range
The assembly supports a DC–3GHz operating range for compatible automotive antenna, communication and RF signal connections.
Wide Operating Temperature
A -40°C to +105°C operating range supports automotive installations exposed to substantial temperature variation.
Frequently Asked Questions
Q1: This cable is a "Left Angle" design; how do I verify its bending direction during actual vehicle installation layouts?
A1: Automotive Fakra elbow directions are defined by international standards: when holding the connector facing the interface cross-section directly, with the plastic retaining clip oriented at the top facing you, the cable exits 90-degree vertically toward your left hand. This is the standard Left Angle format. This asymmetric lateral layout enables wires to run skin-tight along wall lines directly to the left after mating inside compressed bumper walls, seamlessly escaping installation dead zones.
Q2: Compared to generic straight cables, will this 90-degree left-angle setup trigger severe reflections or VSWR spikes across 4GHz+ RF bands?
A2: Forcing soft coax wires into hard bends warps inner shapes, plunging line impedance and collapsing data frames. This Premier Cable product overcomes this by housing a monolithic, rigid precision right-angle metal bus-bar terminal inside the right-angle shroud, with geometric tolerances at curves controlled via micro-scale molding. This clamps insertion loss and Voltage Standing Wave Ratio (VSWR) well inside safe vehicle guidelines, flawlessly guiding uncompressed RF streams.
