MIN Size 7/8" Male To M12 Female Adapter
Premier Cable Co., Ltd is one of the leading min size 7/8" male to m12 female adapter manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
Our MIN size 7/8" male to M12 female adapter are designed for applications that require converting a 7/8"-16 UN interface to an M12 interface. The adapter features gold-plated conductors to ensure superior electrical performance and corrosion resistance. The 7/8"-16 UN male 5-pin and M12 female 5-pin design mates with 20AWG cable and has an overmolded plug for durability and easy installation. The orange color allows for quick identification, making it an ideal choice in industrial environments.
Specifications
| Product name | 5 Pole Male 7/8UN2 to 5 Pole Female M12 Adapter |
| Drawing No. | PCM-S-0405 |
| Connector 1 | 7/8"-16 UN-2B connector (5-pin; male) |
| Connector 2 | M12 connector (5-pin; A-coded; female) |
| Jumper wire | 20AWG |
| Conductor | Gold plated |
| Housing material | PVC |
| Advantages | - Robust and industrial grade - For reliable and fast connecting - Additional flexibility |
| Protocol | DeviceNet, NMEA2000 |
Features
High-quality conductors: Gold-plated conductors provide excellent conductivity and corrosion resistance.
Flexible connection: Mini trunk to micro drop Tee adapter is suitable for a variety of devices.
Durable design: Overmolded plug ensures the robustness and durability of the connection.
Easy to identify: Orange design for quick identification in complex wiring environments.
Wide application: Suitable for industrial automation, equipment connection, and other scenarios requiring a reliable connection.
Applications
- Sensor connection: Circular connector adapters M12 to 7/8" can be used to connect different types of sensors to the control system or PLC to ensure reliable transmission of data and signals.
- Actuator connection: Mini Change to Micro Change connector can be used to connect the actuator to the control unit, transmit control signals, and achieve precise control.
- Industrial Robot: In the robot system, ensure the stable power and signal connection between components.
- Distribution System: DVN cable adapter trunk line to drop line connector can be used for signal and power transmission between power equipment to ensure stable operation of the system.
