Automotive HSAutoLink 12 Pin Connector To USB 3.0 Cable Assembly
PCM Cable Co., Ltd. is one of the leading automotive hsautolink 12 pin connector to usb 3.0 cable assembly manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
This automotive harness has a HSAutoLink 12-pin plug on one end and a USB 3.0 Type A female plug on the other end. It is mainly used to connect the vehicle system or device to external devices to transmit high-speed data and power.
Specifications
| Product name | HSAutoLink automotive cable 12-pin HSAutoLink connector to USB 3.0 cable assembly |
| Connector 1 | HSAutoLink connector, 12pin (Molex 111146-3080 compatible) |
| Connector 2 | USB 3.0 connector, type A, female |
| DWG No. | PCM-ZC-0060 |
| Cable length | Customized |
| Cable marking |
E492515 AWM STYLE 2725 80° 30V VW-1 SUPER HIGH SPEED USB Revision 3.0
|
| Data transmission rate | Up to 5Gbps |
How to use
- Connect the HSAutoLink end: Insert the HSAutoLink 12-pin plug into the port of the vehicle system or device, making sure the connection is secure and reversed.
- Connect the USB end: Connect the USB 3.0 Type A female plug to an external device (such as a computer, USB drive, etc.).
- Check the power supply: Make sure that the device and the automotive harness can provide sufficient power, especially for devices that require power such as external hard drives.
- Data transfer: After connection, high-speed data transfer or device control can be started between devices.
- Disassembly and storage: After use, disassemble and properly store the automotive harness in reverse order to avoid damaging the connector.
Tip:
Avoid excessive bending or pulling of the cable, and keep the connector clean.
