Fakra Code D Violet Straight Plug To SMA Plug Cable RG-174
PCM Cable Co., Ltd. is one of the leading fakra code d violet straight plug to sma plug cable rg-174 manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
This Fakra Code D Violet Straight Plug to SMA Plug Cable uses RG-174 coaxial cable and is designed for automotive electronics and communication systems to ensure high-quality signal transmission. Fakra Code D Purple Straight Plug is widely used in car entertainment systems, car cameras, navigation devices, etc., while the SMA plug end can be used to connect wireless communication devices, antennas and other high-frequency applications. The cable has excellent signal stability, low loss and anti-interference capabilities, and is suitable for high-demand application environments in the automotive field.
Specifications
| Product name | Antenna extension RG174 coaxial cable SMA male to Fakra D male |
| DWG No. | PCM-0784 |
| Connector 1 | Fakra connector, male, rear mount, straight, D code |
| Connector 2 | SMA connector, male |
| Cable length | 15cm or customized |
| Wire | RG174 coaxial cable |
| Cable diameter | 2.8mm |
| Cable impedance | 50 Ohm |
| Recommend cutout size | 6.5mm |
| Nut | 1/4"-36UNS-2B |
| Waterproof rating | IP67 |
| Spray test | 48 hours |
Applications
- In-vehicle wireless communication systems
- In-vehicle navigation and entertainment systems
- In-vehicle cameras and security monitoring
- Automotive sensors and radar systems
- High-frequency communication equipment and wireless infrastructure
