Low Profile DB9 RS232 Cable DB9 Male Straight To DB9 Female Right Angle Cable
dimensions pin assignment drawing of D-Sub Cable DB9 RS232 Serial Cabe Male to female left right angle
Low profile DB9 serial rs232 right angle extension cable
Space saving right angled D-Sub 9 Pin DB9 Male to female rs232 serial cable
Low Profile DB9 RS232 Cable DB9 Male Straight To DB9 Female Right Angle Cable
PCM Cable Co., Ltd. is one of the leading low profile db9 rs232 cable db9 male straight to db9 female right angle cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
Upgrade your connectivity with our Low-Profile DB9 RS232 Cable, designed for applications where space is limited. This cable features a DB9 male straight connector on one end and a DB9 female right-angle connector on the other, making it ideal for tight installations and hard-to-reach areas.
Specification
| Product name | Space saving right angled D-Sub 9 pin DB9 male to female RS232 serial cable |
| DWG No. | PCM-0495 |
| Connector 1 | DSUB 9 pin, female, low-profile, right angle, left angle |
| Connector 2 | DSUB 9 pin, male, straight |
| Cable length | 1m, 2m, 3m, 5m, or customized |
| Wire gauge | 28AWG |
| Cable diameter | 5.0mm |
| Cable jacket | UL2464 PVC |
| Outlet direction | With 5 pins on top, the cable exits to the right |
Features
90-degree angled design:
- Adopt DB9 female 90-degree angled design to optimize space utilization.
- Suitable for compact industrial, medical and commercial equipment connection scenarios.
Low profile plug:
- The DB9 female plug is low-profile and lightweight, reducing space occupation.
- Provides efficient connection without affecting equipment operation and maintenance.
Multiple direction options:
Users can choose the outlet direction according to their needs: left, right, up, down or 45 degrees to ensure optimal cable management.
Application
- Industrial automation equipment: The right-angle DB9 RS232 cable is suitable for connecting control cabinets and rack-mounted equipment in compact spaces.
- Medical equipment: The left-angle DB9 null modem cable Provides reliable connections for high-density equipment in medical environments.
- Commercial equipment: The 90-degree angled rs232 extension cable supports POS systems, banking equipment, and various terminal devices.
