XT90 Male To Female Panel Wire

PCM Cable Co., Ltd. is one of the leading xt90 male to female panel wire manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.

The XT90 Male to Female Panel Mount Cable (Part Number: PCM-0976), newly developed by Premier Cable, is a chassis-level connectivity solution tailored for high-power industrial equipment. Featuring an innovative design, this product integrates a securing flange with reserved screw holes on both sides of the XT90 connector, allowing it to be perfectly locked onto control panels, chassis bulkheads, or battery enclosures. This design overcomes the limitations of traditional floating cables, enabling users to perform safe and rapid high-current charging or discharging from the outside without opening complex device housings.

Internally, the cable utilizes large-gauge, multi-strand high-purity tinned copper cores wrapped in a highly flexible, high-temperature resistant silicone insulation layer, maintaining stable physical properties under extreme cold or high-heat conditions. The terminal contacts adopt a thick brass gold-plating process, which significantly reduces contact resistance and controls localized heat generation under heavy loads, ensuring the safe conduction of 90A continuous current.



Additionally, the panel end is equipped with an integrated rubber waterproof and dustproof sealing cap, effectively blocking moisture and sand from entering when the equipment is in transit or idle. Whether applied to violently vibrating industrial drones, heavy-load energy storage batteries, or high-precision automated robotics, this panel mount cable delivers a rock-solid electrical barrier.

◆    Core Advantages & Stable Connection

As a high-quality XT90 panel fix connector, the core technology of this cable assembly lies in its outstanding ultra-low impedance performance. The internal conductors utilize internationally safety-certified large-gauge ultra-flexible silicone wire, capable of reliably carrying 90A continuous heavy current (with peaks up to 120A). The interface features heavy gold-plated brass terminals, ensuring tight mating and optimal electrical conductivity. The unique flanged panel-mount XT90 plug design allows screws to lock the connector firmly onto the control dashboard. When subjected to high-frequency mechanical vibrations-such as industrial UAVs flying at high speeds or AGVs driving over bumpy terrains-it guarantees a rock-solid electrical connection, completely eliminating the risk of power cuts caused by loose contacts.

◆    Manufacturing Workmanship & Installation Requirements

In terms of production manufacturing, Premier Cable implements industry-leading integrated injection overmolding technology. The junction between the cable and the connector is thickened and reinforced, providing excellent anti-pull and anti-bending strength. The panel end of the product is designed with standard countersunk screw hole spacing, perfectly meeting the installation requirements for various control panel punch-outs, battery enclosures, distribution boxes, and plastic or metal chassis bulkheads. Encased in high-spec high-temperature resistant silicone insulation, the cable retains superior flexibility even in extreme ambient temperatures ranging from -60°C to +200°C. Its small bending radius makes internal routing layouts in cramped equipment housing effortlessly neat.

◆    Extended Lifespan & Protective System

To substantially prolong the service life of high-power industrial equipment, the panel-mount end is specially equipped with an integrated rubber waterproof and dustproof protective cap. When the equipment is idle-such as during outdoor solar energy storage operations, agricultural drone spraying, or transit in rain and snow-snapping the seal cap shut effectively delivers IP-level protection, blocking moisture, sand, and chemical elements from entering the housing to prevent gold-finger oxidation. The connector offers an exceptionally high mating cycle lifespan, maintaining robust spring tension even after thousands of cycles. It serves as an indispensable hardware safety barrier for building highly trustworthy outdoor power connections, solar battery storage installations, and heavy-load industrial drone power systems.

●    Side-Ear Screw Flange

The panel end adopts a unique dual-ear screw hole design, locking directly onto the control panel.

●    Dust & Waterproof Seal Cap

The interface features a wear-resistant integrated rubber cover to seal out external moisture and debris.

●    Asymmetric Fool-Proof Shell

Retains the classic XT90 asymmetrical trapezoidal contour, eliminating reverse polarity at the source.

●    Industrial-Grade Insulated Housing

 Moded from thickened tough insulating material, offering extreme impact and crush resistance.

Solar & Lithium Storage Systems



Applied in portable power stations, solar inverter chassis, outdoor charging piles, and high-voltage battery packs.

RC Models & E-Mobility



Used for large-scale RC models, intelligent AGV robots, off-road electric scooters, and e-bikes.

Q1: Does this XT90 panel mount cable support custom wire gauge (AWG) and length?

A1: Yes. Premier Cable features mature supply chain and manufacturing capabilities. We can customize high-spec silicone wires such as 8AWG, 10AWG, or 12AWG, and adjust lengths based on your actual continuous current requirements and drawings.

Q2: Are mounting screws included for the panel-fix end? How is the sealing effect of the waterproof cap?

A2: We can provide matching countersunk fixing screws based on bulk purchase orders. The integrated rubber cap fits tightly over the shell, offering outstanding splashproof and dustproof performance when idle, making it ideal for harsh outdoor environments.

Q3: Does the cable generate significant heat when a heavy 90A continuous current passes through?

A3:The product utilizes thick gold-plated brass contacts and high-temp silicone wire (rated up to 200°C). Its ultra-low contact resistance effectively controls heat generation. Operating under rated 90A current, the temperature rise remains strictly within safe industrial standards.
