The PCM-KP-0008 is a purpose-designed 4-port RJ45 experimental interface module that allows engineers to build and test bus-style serial circuits, daisy-chain Ethernet paths, and modular cable–based prototypes with ease.
All four shielded RJ45 connectors are parallel-wired, forming a compact hub suitable for bridging, tapping, or expanding communication lines in development environments.
The integrated bus board + breakout board layout reduces wiring clutter and offers a clean structure for troubleshooting and iterative testing.
Made directly in our factory, this DIN-mounted module offers consistent build quality and is ideal for R&D labs, field engineering benches, or on-machine testing.
Specification
| Product Name |
RJ45 8P8C DIN Rail Mount Ethernet Connector Distribution Breakout Board, Four-Way Parallel Connection RJ45 Vertical Jack Terminal Block Connector |
| DWG No. | PCM-KP-0008 |
| RJ45 Ports | 4 × Shielded RJ45, parallel-wired |
| Terminal Block | Screw terminals for all 8 lines + shield |
| Wiring Pitch | 3.81mm |
| Wire Range | 18–26AWG |
| Housing | KPRH72mm, green |
| Installation | 35mm DIN Rail |
| Structure | Integrated bus board + breakout board |
| Use Case | Prototyping, daisy-chain wiring, signal tapping |
| Customization | Pinouts, labeling, colors, OEM available |
Design Highlights
Integrated Bus + Breakout Architecture
Instead of separating distribution and termination, the PCM-KP-0008 places both functions onto one module. This allows real-time measurement, injection, or modification of any line during testing.
Suitable for Daisy-Chain Networking
The four parallel-wired RJ45 ports allow fast creation of Daisy-Chain topologies commonly used in:
- Serial communication buses
- Multi-node device chains
- Machine-to-machine expansion links
Full Screw Terminal Accessibility
Every one of the 8 signal lines + shield is available through screw terminals, enabling:
- Quick signal tapping
- Line redirection
- Probing and debugging
- Rapid prototyping of alternative pinouts
Ready for Panel or Lab Use
Mounted on a 35mm DIN rail, the module fits neatly into both industrial cabinets and engineering workbenches.
Practical Engineering Use Cases
- Building/modifying prototype circuits using modular RJ45 cables
- Rapid testing of multi-device communication loops
- Creating temporary distributed networks during equipment debugging
- Measuring or injecting signals directly into individual RJ45 lines
- Prototyping RS485/RS422/serial-based systems that use RJ45 pinouts
- Training or lab environments involving Ethernet-style wiring experiments
