We are a professional manufacturing factory focusing on high-density connection cable solutions, providing a full range of Micro-D cable assemblies to meet the stringent requirements of small-volume, high-reliability I/O connections in industry, military, testing, and medical. This Micro-D Cable Assembly Micro DB25 to Blunt Cut is equipped with a standard 1.27mm pitch Micro-D male connector on one end, and an unterminated design (cut bare wire) on the other end, which is convenient for customers to process and access by themselves. The entire cable uses 28 AWG high-quality copper conductors, equipped with a shielding layer and PVC insulation layer, which effectively reduces crosstalk and external electromagnetic interference, ensuring stable and reliable signal transmission.
Specification
| Product name | Cable Assembly, 25 Pin Micro-D to Unterminated with Cut Ends, Suitable for LXI DIO Trigger |
| Compatible with |
Molex 834249019; Molex 834249020; Molex 834249021; Molex 834249014 |
| DWG No. | PCM-S-0663 |
| Connector type (End A) | 25-Pin 1.27mm pitch Micro-D |
| Gender (End A) | Female |
| Securing method (End A) | 2-56 UNC, OD: 5.0x37.5mm, nickel plated |
| Suitable for Pickering switch products | Yes |
| Connector type (End B) | Cut ends |
| Connector size | 1/3 smaller than traditional D-Sub, saving installation space |
| Cable length | 1m |
| Wire gauge | 28AWG*25C |
| Cable diameter | 8mm |
| Cable jacket | PVC, UL2464 |
| Application | Compatible with Pickering LXI DIO/trigger ports, suitable for high-density I/O connection requirements in aviation, medical, test equipment, automation control, communication interfaces, etc. |
Features
- Factory direct supply, quality assurance: All products are produced by us, supporting batch customization and controllable delivery time.
- Standard specifications with strong compatibility: 25-pin Micro-D male connector, compatible with mainstream Micro-D interfaces.
- Unterminated design for flexible access: The other end of the cable is designed with cut bare wires, which is convenient for users to connect to customized interfaces, terminal blocks or PCBs.
The series of products is rich and supports a variety of pin position options
This series of Micro-D cable assemblies provides three standard pin positions to meet different interface requirements:
- 9-pin Micro-D cable assembly
- 15-pin Micro-D cable assembly
- 25-pin Micro-D cable assembly (current product)
About us
As a cable manufacturer, we have more than 10 years of experience in manufacturing high-density connection cables. The factory has complete wire cutting, welding, injection molding, testing, assembly and quality control capabilities, supports OEM/ODM cooperation model, welcome to consult and customize with drawings and samples.
