h-Coupler M12 Power L-code Extension Cable

M12 L-Code Connector 16A 63V H-Splitter

Name: Customized M12 L-Code Connector 16A 63V H-Splitter Suppliers, Manufacturers - Wholesale Quotation - PREMIER - PCM
Brand: Premier Cable
SKU: 227234573

h-splitter, M12, male/female, straight, 4+FE, L-coded, POWER

Send Inquiry

Product Introduction

PCM Cable Co., Ltd. is one of the leading m12 l-code connector 16a 63v h-splitter manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.

M12 L-Code Connector 16A 63V h-Splitter is a type of electrical connector used to transmit signals or power in industrial automation systems. It is designed to provide a reliable and sturdy connection for Ethernet applications while providing a compact and easy-to-use form factor.

Specification

Product name	M12 Power connector L-code Small h-Splitter
Drawing No.	PCM-S-0420
Connector A	Male, M12 connector, L-code
Connector B	Female, M12 connector, L-code
Number of contacts	5
Mechanical life	> 100 Mating cycles
Rated voltage	63 VDC
Current	16 A
Shape option	h-Splitter, Y-Splitter, T-Splitter
Features	By utilizing T, Y, and H-splitters, significant cost savings on cabling can be achieved. By effectively threading M12 cables through machinery and branching them with splitters, the total length of cabling can be shortened.
Compatible	Turck M12 Power Junction Systerm Small H Splitter L-code; ESCHA M12 h-Splitter PL-3HM12-S5-2K5

About US

Premier Cable produces M8, M12, 7/8", and other related series products in various forms, including A code, B code, D code, K code, L code, M code, S code, T code, and X code. The products are available in plastic assembly type and metal shielding type. The number of pins is optional from 2 pins, 3 holes, 4 pins, 4 holes, 8 pins, to 12 pins, etc. The adapter shapes include Y-type, T-type, and H-type. Different shapes meet different industrial environments.
