Modular RJ45 Resistor Termination Plug
PCM Cable Co., Ltd. is one of the leading modular rj45 resistor termination plug manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
This modular RJ45 resistor termination plug is not only suitable for wide area network (WAN), integrated services digital network (ISDN), telecommunications distribution frame (Telco IDF/MDF) and CPI Bus system, but also can be applied to the cable end of DMX512 lighting control system to prevent signal reflection and interference and ensure stable signal transmission. We provide a variety of commonly used resistance values such as 120 ohms, 110 ohms, 100 ohms, 60 ohms, and support the customization of the number and value of resistors to meet diverse needs.
Specification
| Product name | RJ45 Resistor Terminating Plugs |
| Interface type | RJ45 |
| Resistor value | 120 ohms (optional 110 ohms, 100 ohms, 60 ohms) |
| Shell material | High-strength plastic |
| Contact material | Gold-plated contacts |
| Number of resistors | Customizable |
| Resistor location | Across pins 1/2; across pins 3/6; across pins 4/5; across pins 1/2 & 3/6; across pins 4/5 & 3/6, etc. |
Features
- Multi-purpose terminator: This RJ45 DMX terminator is not only used for communication and network, but also supports the DMX512 system, providing a wide range of application scenarios.
- Multiple resistance values are optional: the default is 120 ohms, and other resistance values include 110 ohms, 100 ohms, and 60 ohms, which can be customized to meet different needs.
- The number of resistors can be customized: flexible resistor configuration is provided according to customer requirements.
- Standard RJ45 interface: The DMX terminator is compatible with various network devices and DMX512 lighting control systems, with stable and reliable connection.
- High-quality materials: high-strength plastic shell and gold-plated contacts ensure long-term durability and clear signal.
- Easy installation: plug and play design, no special tools required, easy to operate.
Application
- WAN (Wide Area Network): The RJ45 terminator is used in large networks to ensure stable data transmission in long-distance communications.
- ISDN (Integrated Services Digital Network): ISDN RJ45 terminator can effectively terminate lines to prevent signal conflicts.
- Telco IDF/MDF (Telecommunications Distribution Frame): Ensures the stability of signal terminals.
- CPI Bus System: RJ45 plugs with 120 ohm resistor can be used in industrial networks to ensure stable data communications.
- DMX512 Cable Termination: Terminates signals in DMX512 systems such as stage lighting and architectural lighting to prevent signal bounce and interference.
How to use
Connect the RJ45 terminator to the network device or the end of the DMX512 signal link to terminate the signal transmission and eliminate reflections. Choose the appropriate resistance value according to different devices and customize the number of resistors to meet specific needs.
Product advantages
- Suitable for dual applications of communication and DMX512 control systems.
- Multiple resistance values and resistor number customization options.
- Improve the stability of signal transmission and prevent signal reflections.
- Rugged design and simple operation
