Camera Link HS (CLHS) cables use Infiniband technology to provide high-speed, high-bandwidth data transmission, and are mainly used in machine vision, industrial automation, and other applications that require high-speed image transmission. CX12 cable and CX4 cable are two different versions of CLHS cables, which differ in transmission rate, connection configuration, and application scenarios. The following is a comparison between the two:
| Feature | CX12 Infiniband Cable | CX4 Infiniband Cable |
| Data Rate | Up to 12Gb/s per channel | Up to 4Gb/s per channel |
| Number of Channels | 12 channels | 4 channels |
| Application Scenarios | High resolution, high frame rate | Moderate resolution and frame rate requirements |
| Transmission Distance | Shorter (15m-50m for copper, longer for fiber) | Longer (50m-100m for copper, longer for fiber) |
| Application Fields | High-end machine vision, industrial automation, large-scale monitoring | Standard machine vision, video surveillance |
| Cost | Higher | Lower |
CX12 Infiniband Cable
The CX12 Infiniband cable is a high-performance cable designed for applications that require extremely high bandwidth and fast data transfer. It supports data transfer rates of up to 12Gb/s per channel and provides up to 12 channels, making it ideal for applications that need to process high-resolution images, such as 8K video streaming, advanced industrial automation, and large-scale surveillance systems. CX12 cables are suitable for shorter transmission distances, typically between 15m and 50m for copper cables, while fiber optic cables can provide longer transmission distances. With its excellent data transfer rate and reliability, the CX12 Infiniband cable is ideal for high-end machine vision and data-intensive tasks.
CX4 Infiniband Cable
The CX4 Infiniband cable is a versatile and cost-effective solution for applications that require moderate data transfer rates. It supports a maximum transfer rate of 10Gb/s per channel and supports up to 4 channels, suitable for 4K video streaming, standard machine vision systems, and video surveillance applications. Compared with CX12 cables, CX4 cables have longer transmission distances in copper cables, typically up to 50 meters to 100 meters, and fiber optic cables have even longer transmission distances. Due to its lower cost and reliable performance, CX4 cables provide extremely high cost-effectiveness while meeting bandwidth requirements, making them suitable for use in standard industrial vision systems.
In summary, CX12 cable is more suitable for high-end applications that require ultra-high bandwidth and data processing capabilities, while CX4 cable is better for standard machine vision and video surveillance systems with moderate bandwidth needs and a lower cost.
