Battery Energy Storage Connectors 150A
150A Battery Storage Connector size dimensions
150A Energy Storage Connector High Current 35mm² Plug
150A Power Connector Black Battery Storage High Voltage Plug
High Current 120A Battery Connector Black 1000V Energy Storage
Battery Energy Connector 150A Black Safe High Voltage IP67
Battery Energy Storage Connectors 150A
PCM Cable Co., Ltd. is one of the leading battery energy storage connectors 150a manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
This 150A battery energy storage connector is designed for high-power applications such as battery packs, renewable energy storage, and industrial backup systems. With a rated current of 150A, supporting 35mm² (24AWG) cables and a 8.0mm Radsok, it ensures efficient power transmission. The UL94-V0 flame-retardant nylon housing and IP67 waterproof sealing provide durability and safety in demanding environments.
Specifications
| Product Name | Energy Battery Storage Connector Right Angled |
| DWG No. | PCM-150A-BL |
| Rated Current | 150A |
| Cross-Section Wire | 35mm² (24AWG) |
| Radsok Size | 8.0 mm |
| Plastic Material | Nylon UL94-V0 (Black) |
| Sealing Ring | Silicone |
| Metal Body | Copper, Silver/Tin Plated |
| Crown Spring | High Conductivity Copper, Silver/Gold Plated |
| Rated Voltage | 1000V DC |
| Dielectric Strength | 3000V DC |
| Contact Resistance | 0.2 mΩ |
| Mating Cycles | 1000 times |
| Temperature Rise | 50K |
| Waterproof Rating | IP67 |
| Operating Temp. | -40°C to +125°C |
Applications
The 150A battery energy storage connector is ideal for battery energy storage systems, industrial backup power, renewable energy storage, and electric vehicle (EV) battery packs. Its high-current 150A capacity and IP67 waterproof design ensure reliable connections in high-voltage DC applications, while the robust 35mm² cable compatibility and modular drawer-style system simplify installation and maintenance. Perfect for solar and wind energy storage, UPS systems, and other high-power energy storage applications, this connector provides safe, durable, and efficient power transmission across a wide range of industrial and commercial scenarios.
