350A Energy Storage Connector
PCM Cable Co., Ltd. is one of the leading 350a energy storage connector manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
When safety, visibility and serviceability matter on the pad or in the field, this 350A Energy Storage Connector shines - literally. The bright orange housing signals high-voltage circuits at a glance while delivering dependable 350A performance through a massive 12.0 mm Radsok contact. Built for large-scale solar farms, wind-turbine battery zones and containerized megawatt storage, this connector simplifies operations and reduces human error during installation and maintenance.
benefits
- Safety first: High-visibility orange housing for fast HV identification during commissioning and service.
- Field-ready: IP67 sealing and UV-resistant nylon ensure years of outdoor exposure with minimal upkeep.
- Fast maintenance: Drawer-style or slide-in deployment enables quick swaps of battery modules without rewiring.
- Energy efficiency: Low contact resistance (0.2 mΩ) and 12.0 mm Radsok contact minimize thermal losses - better round-trip efficiency for your BESS.
Specifications
| Product Name | High Current Power Storage Connector 350A 120mm² |
| DWG No. | PCM-350A-OR |
| Rated Current | 350A |
| Cross-Section Wire | 4/0 AWG (120mm²) |
| Radsok Size | 12.0 mm |
| Plastic Material | Nylon UL94-V0 (Orange) |
| Sealing Ring | Silicone |
| Metal Body | Copper, Silver/Tin Plated |
| Crown Spring | High Conductivity Copper, Silver/Gold Plated |
| Rated Voltage | 1000V DC |
| Dielectric Strength | 3000V DC |
| Contact Resistance | 0.2 mΩ |
| Mating Cycles | 1000 times |
| Temperature Rise | 50K |
| Waterproof Rating | IP67 |
| Operating Temp. | -40°C to +125°C |
Use cases
- Containerized ESS: color-coded connectors speed repairs and prevent mismating inside containerized storage units.
- Solar farm battery banks: rugged IP67 connectors that endure outdoor cycles and simplify module replacement.
- Commercial EV depot charging hubs: reliable high-current distribution to large battery arrays and charging infrastructure.
- Industrial microgrids: scalable connectors for power units that must be swapped quickly during scheduled maintenance.
Quick install & field tips
- Always use certified 4/0 AWG lugs and heavy-duty crimp tools; verify crimp integrity and insulation penetration.
- Check silicone seals after repeated services; replacement seals are available.
- Color coding helps with lockout/tagout and technician safety protocols - orange = HV/high-power circuit.
