Quad TE MATE-AX Mini Fakra To Fakra Automotive Cable Assembly
PCM Cable Co., Ltd. is one of the leading quad te mate-ax mini fakra to fakra automotive cable assembly manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
The MATE-AX connector system, developed by TE Connectivity, represents the new benchmark for high-speed automotive data interfaces. Compact and shielded, it delivers the electrical performance of coaxial Fakra in a fraction of the space - making it ideal for modern vehicle architectures where bandwidth and packaging density are both critical.
By combining it with traditional Fakra male connectors, the PCM-ZC-0050 serves as a conversion link between MATE-AX domain controllers and Fakra-based sensors or cameras, simplifying upgrades, retrofit projects, and validation setups.
This hybrid harness allows engineers to:
- Test new MATE-AX-enabled ECUs with existing Fakra modules
- Prototype Ethernet-based zonal topologies
- Maintain backward compatibility while transitioning to next-gen standards
Specifications
| Product name | 4-in-1 MATE-AX to 4× Fakra Cable | High-Speed Automotive RF Cable Assembly |
| DWG | PCM-ZC-0050 |
| Connector 1 | Original TE Mate-AX connector, 2-2298721-9, 4-in-1 mini Fakra connector, female |
| Connector 2 | 4 x TE Fakra connector, male, TE 2-2326914-0 |
| Wire | Dacar 302-4 |
| Cable length | 0.5m, 1m, 2m, or customized |
| Cable impedance | 50 Ohm |
| Data rate | DC - 6GHz |
Built for Integration and Flexibility
Whether you are developing camera modules, Ethernet gateways, or sensor fusion ECUs, this cable gives your design team flexibility to mix connector systems without signal degradation.
Premier Cable's in-house production ensures:
- Fast turnaround for prototyping and pilot runs
- No MOQ, ready-to-ship stock
- Engineering drawing support for OEM projects
It's not just a cable - it's a system integration enabler between old and new automotive signal ecosystems.
Why Choose Premier Cable
With decades of expertise in automotive Ethernet and RF harnesses, Premier Cable has become a trusted OEM partner for engineers integrating Rosenberger, TE, and Molex systems.
Our factory-grade production of MATE-AX, H-MTD, HSD, MATEnet, HSAutoLink, and Fakra assemblies ensures signal stability even in harsh automotive environments - enabling your designs to meet tomorrow's bandwidth and reliability demands.
