HSD 4+2 Cable Right Left Angled 6 Pin Wire
PCM Cable Co., Ltd. is one of the leading hsd 4+2 cable right left angled 6 pin wire manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.
Premier Cable PCM-ZC-0153 is an HSD 4+2 high-speed automotive cable assembly developed for space-constrained vehicle electronics. Its left- and right-angle connector geometry directs the cable laterally, reducing the rear clearance normally required by straight connectors.
The HSD 4+2 architecture is suitable for high-speed differential data together with auxiliary electrical circuits in smart cockpits, displays, camera systems, infotainment units and automotive controllers.PCM-ZC-0153 uses an HSD 4+2 interface architecture that combines HSD high-speed differential connectivity with additional electrical contacts.This arrangement helps consolidate data and auxiliary circuits within one interface, reducing separate connections and simplifying harness organization in cameras, displays, controllers and infotainment modules.
◆ Core Advantages & Stable Connection
As a highly reliable HSD 4+2 automotive high-speed connection line tuned to zero-compromise signal integrity, the core technological advantage of the PCM-ZC-0153 centers on locking an unyielding digital pipeline within high-noise zones. Within electronic control bays where massive power conduits and fast switching relays generate complex mutual coupling feedback, airborne electrical distortion threatens signal loss. This cable utilizes a matrix-balanced 4+2 pin structure where the differential signal pairs are tightly balanced within a standard 100-ohm impedance envelope. Armored behind a full-wrap seamless metallic capsule and high-coverage tin braid shields, it constructs a complete Faraday envelope that entirely deflects external RFI/EMI spikes. Locked via its robust mechanical spring latching clip, the terminal interface remains perfectly flush to defeat aggressive chassis vibrations and maintain a stable connection that freezes screen flickering.
Products Specification
| Product Type | HSD 4+2 Pin Z Code Cable |
| Drawing Number | PCM-ZC-0153-X |
| P1 Connector | HSD 4+2 Pin Jack, Z Code, Straight |
| P2 Connector | HSD 4+2 Pin R/A Jack, Z Code, Right Angle |
| P1 Compatible Model | Compatible with Rosenberger 99K11D-1D5A5-Z |
| P2 Compatible Model | Compatible with Rosenberger 99K20K-1D5A5-Z |
| Cable Length | 1000 + 20 mm |
| Characteristics impedance | 100 O Nominal |
| Frequency Range | DC-2 GHz |
Products Display
Product Features
Left/Right Angled Elbow Geometry:
Both plug ends feature custom 90-degree left and right bending profiles, minimizing rear clearance depth behind electronics.
4+2 Dedicated Pinout Topology:
Integrates a standard 4-pin high-speed differential cluster combined with 2 standalone power/ground circuits (6-pin layout).
Secondary Snap-Fit Interlocking Latch:
The housing incorporates a heavy-duty physical locking wedge, delivering tactile feedback and solid strain resistance upon mating.
Asymmetrical Color-Coded Housing:
The connector assembly complies with global car codes using specific color-keying housings to completely prevent orientation errors.
Core Application Scenarios
ADAS & Megapixel Sensing Arrays
Designed for ADAS and intelligent sensing systems, this HSD 4+2 cable can connect megapixel surround-view cameras, HD vision modules, ultrasonic sensors, and central autonomous-driving domain controllers. Its high-speed differential architecture supports compact data and auxiliary signal routing, while the left/right 90° connector geometry simplifies installation around space-constrained cameras and sensing modules. It is well suited for 360° surround view, automated parking, blind-spot monitoring, obstacle detection, and multi-sensor fusion applications.
Telematics Gateways & High-Density Head Units
Suitable for high-speed backbone connections among infotainment Head Units, central gateways, TCUs, digital clusters, and cockpit control modules. The HSD 4+2 architecture integrates differential data and auxiliary circuits within a compact interface, helping reduce connector and harness complexity. Left/right-angle exits also route the cable close to the enclosure or PCB, minimizing rear-panel congestion in high-density IVI, telematics gateway, and smart cockpit systems.
Core Performance Advantages
● Gigabit-Class Jitter-Free Throughput:
Differential impedance is tuned to absolute margins, forcing uncompressed high-bitrate media and ethernet packets to stream with zero loss.
● 360° Full Faraday Cage Isolation:
Armored with a dense multi-layer shield matrix and internal metallic hoods, aggressively capturing erratic intra-cabin RFI/EMI noise.
● Anti-Resonance Telemetry Continuity:
Validated against intense cabin shudders and low-frequency chassis shockwaves, eliminating micro-displacement signal drops during transit.
● Thermal Extreme Conductor Protection:
The modified high-flex skin shrugs off severe temperature cycles under the dash, maintaining structural resilience over decades.
Frequently Asked Questions
Q1: How do the "Left Angled" and "Right Angled" 90-degree hoods complement each other on both ends of this HSD 4+2 cable? Will the exit paths conflict?
A1: Our right-angled plugs are engineered with a dedicated complementary routing layout. One end directs the wire egress to the left, while the opposite end sweeps it flush to the right. This layout perfectly bridges asymmetrical configurations where the master controller interface sits leftward and the dashboard screen socket aligns rightward. Both cable ends wrap tightly against the device casing faces, crushing backplane clearance down below 15mm without inducing wire torsion or spatial conflict.
Q2: Do the extra "+2 pins" in the core layout support Power over Coax (PoC) or high-current remote sensor feeding?
A2: Yes, fully. While the core 4-pin matrix routes high-bandwidth differential differential pairs, the supplementary +2 pins are custom-wired with low-DCR, high-cross-section vehicular copper cores. It natively supports Power over Coax (PoC) topologies and safely carries standalone continuous currents up to 2A to 3A, engineered to deliver ultra-stable power feeding to distant LiDAR grids and megapixel cameras.
Q3: Automotive HSD connectors specify different mechanical keying codes (e.g., Code A, B, C, etc., managed via color and slot ribs). Can we customize the keying configuration?
A3: Absolutely. Premier Cable maintains a highly comprehensive array of HSD automotive tooling components on our factory floor. While the stock PCM-ZC-0153 ships with a standardized universal keying profile, as a tier-1 source plant with autonomous R&D design capacity, we fully support wholesale buyers to customize across standard vehicular Code A, B, C, D, E, F through Z keyings with strict matching color shrouds. Every batch undergoes rigid mechanical mating tolerance verification to ensure micro-precision supply chain integration.
