V90 Servo Motor Encoder Cable

PCM Cable Co., Ltd. is one of the leading v90 servo motor encoder cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.



The Pre-assembled Signal Cable 6FX3002-2DB10 is specifically designed for use in the ABS encoder of the S-1FL6 LI. This power cable is part of the MOTION-CONNECT 300 connection system that connects the SINAMICS V90 servo vector drive to the SIMOTICS S-1FL6 servo motor.



Specification



Product name	Servo Absolute Encoder Cable
Model	6FX30022DB201AD0
Connector 1	SCSI MDR 14 Pin
Connector 2	VGA Female
Usage	ABS. encoder S-1FL6 LI low inertia 0.05Kw...1KW motor
Material	Pure copper
Contact	Gold plating
Type of wire	Signal wire
Cable jacket	PVC / PUR
No. of cores x cross-section	3x 2x 0.20+2x2X0.25 mm²
Drag chain times	more than 8 million times
Rated voltage UO/U	30V/300V
Conductor	Special high-flexibility design fine bare copper multi-strand wire (0.08)



Features





1. Environmentally friendly outer quilt material: imported polymer polyvinyl chloride

2. Twisted pair shielding, double shielding protection, shielding rate >85%, strong anti-interference, making the machine run stably



3. High-precision oxygen-free copper, low resistance, strong conductivity, ultra-fine copper wire to ensure soft wire



4. 8 million bending signal control cable



5. Adopt MDR gold-plated connector: reduce contact resistance and ensure stable signal and transmission



6. Using industrial grade D-SUB connector: with shielded protective metal shell
