RS232 to RS422 converter
RS232 to RS422/485 serial converter

RS232 To RS422 485 Adapter with Cable

Passive bidirectional converter, both RS232 to RS485 converter and RS485 to RS232 converter.

Send Inquiry

Product Introduction

PCM Cable Co., Ltd. is one of the leading rs232 to rs422 485 adapter with cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.

In order to facilitate remote data communication between computers, external devices or intelligent instruments equipped with different standard serial interfaces, the mutual conversion of standard serial interfaces must be carried out.

This RS232 to RS422/485 Converter can convert single-ended RS-232 signals into balanced differential RS-485 signals. The RS232 female port is connected to the RS485 end male connector, and the 485 end is equipped with a terminal block. It has a built-in fast transient voltage suppression protector to protect RS -485 interface

Specification

Product name	RS-232 to RS-422 / 485 Isolated Cable, serial converter
Interface	RS232 (DB9 female) RS485 (4Pin Terminal block) or RS422 (4Pin Terminal block)
Transformer specifications	input AC100～240V 0.5A max. 50-60Hz / output DC5V 2A 10W max
Data Rate	Up to 200 K bps
Power supply	DC5V
RS485 signal	TX+, TX-
RS422 signal	TX+, TX-, RX+, RX-
Shell material	plastic
Length	1m or customized

Features

Signal Conversion: Converts single-ended RS-232 signals to balanced differential RS-485 signals, facilitating communication between devices with different interface standards.

Terminal Block: RS485 terminal block with screw terminals for convenient and secure wiring, ensuring reliable connections.

Voltage Protection: Built-in fast transient voltage suppression protectors safeguard the RS-485 interface from voltage surges and spikes, enhancing equipment protection and reliability.

Compact Design: Compact and lightweight design for easy installation and integration into various setups and environments.

Versatile Compatibility: Compatible with a wide range of devices and applications, including industrial control systems, automation equipment, PLCs, and more.

Application

The RS232 to RS485 converter can be applied to form a point-to-point, point-to-multipoint remote multi-machine communication network between the main control machines, between the main control machine and the microcontroller or peripherals, and realize multi-machine response communication.

It is widely used in the industrial automation control systems, all-in-one card, access control system, consumer system, attendance system, parking lot system, self-service banking system, bus toll collection system, highway toll station system, Programmable Logic Controllers (PLCs), Process Control Systems, Data Acquisition Systems and so on.

Features of RS485 communication

1. Use differential signals.

2. The RS485 communication rate is fast, and the maximum transmission rate can reach more than 10Mb/s.

3. The combination of balanced driver and differential receiver is used inside RS485, which greatly increases the anti-interference ability.

4. The longest transmission distance can reach about 1200 meters.

5. Networked multi-machine communication can be carried out on the bus.

6. The RS485 interface is very simple. The common hardware interface is MAX485

we are a manufacturer of RS232 to RS485 converter
