DIN Valve Adapter With M8 M12 Connection

PCM Cable Co., Ltd. is one of the leading din valve adapter with m8 m12 connection manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.





Premier Cable specializes in the production of DIN valve adapters with M8 M12 connectors to meet the needs of multiple industries and are suitable for a variety of industrial automation equipment. This adapter is not only reliable and durable, but also compatible with products from multiple well-known brands, including Lumberg Automation / Hirschmann's VAD 3C-4-1-M12-5, VAD 1A-1-3-M12-5, VAD 1A-1-3-M8-3, and is widely used in industrial automation, sensors, actuators, machine control and pneumatic systems.





Product name	Solenoid Valve Plug to M12 Cable adapter for Sensor, Hydraulic actuator, Pneumatic actuator, Electromagnetic actuator
Compatible with	Lumberg Automation & Hirschmann VAD 3C-4-1-M12-5, VAD 1A-1-3-M12-5, VAD 1A-1-3-M8-3
Interface	DIN valve plug, DIN 43650 form A (form B and form C are available)
Thread Size	M12 (M8 is optional)
Standard	DIN EN 175301-803
Termination style	Plug connection
Current Rating	4A
Voltage Rating	24 V
IP Rating	IP67
Body style	Right angle
Number of contacts	3 Contact, 5 Contact





• Interface Standard:

1. DIN side: Usually adopts DIN 43650 standard, which is a plug standard widely used in solenoid valves, hydraulic and pneumatic systems.
2. M12 side: M12 connectors are widely used in industrial automation systems, have high protection levels (such as IP67), and can be used in harsh environments.

• Standard Compliance: All valve plugs comply with DIN EN 175301-803 standard, ensuring the consistency and interoperability of the interface.



• High Compatibility: These M12 to DIN 43650 form A sensor actuator cable adapters are compatible with Lumberg Automation and Hirschmann brand devices, ensuring seamless connection with various systems and devices.



• LED Indicator: Each adapter is equipped with an LED indicator to display the connection status in real time for easy operation and maintenance.



• Durable Design: Made of high-quality materials, Hirschmann valve connector to M12 adapter has good durability and resistance to environmental factors, suitable for harsh industrial environments.











• Industrial automation: Thos Solenoid valve plug to M12 cable adapter is used to connect sensors, actuators, and other automation equipment, suitable for various industrial control systems.



• Device interconnection: In applications where devices need to be connected to valves or other components, these adapters provide a stable interface.



• Mechanical engineering: Suitable for various connection requirements in mechanical equipment to ensure the reliability of signal transmission.



• Communication system: In complex communication systems, these adapters can be used for efficient connection between devices to improve the overall performance of the system.





Form A



• Appearance: Square
• Needle Pitch: 18 mm
• Needle Type: U-shaped
• Electrical Characteristics: Rated Voltage up to 250V, Rated Current up to 16A
• Application: Widely used in applications requiring higher current and voltage, such as large machinery and equipment. Suitable for connection requirements of heavy load current.

Form B



• Appearance: Rectangular
• Needle Pitch: 10 mm or 11 mm
• Needle Type: 2 U-shaped and 1 flat piece
• Electrical Characteristics: Rated Voltage up to 125V, Rated Current up to 10A
• Application: Suitable for equipment with medium loads, such as medium-sized industrial equipment and automation systems. Smaller size is suitable for applications in compact spaces.

Form C



• Appearance: Square
• Needle Pitch: 8 mm or 9.4 mm
• Needle Type: Flat piece
• Electrical Characteristics: Rated Voltage up to 125V, Rated Current up to 6A
• Application: Suitable for applications with low current and low voltage, such as sensors and small control devices. Suitable for applications requiring lower loads.









Premier Cable specializes in producing high-quality solenoid valve connection solutions, covering a wide range of models, including DIN valve adapters with M12 or M8 connectors. With advanced manufacturing processes and strict quality control, our products are designed to meet the stringent requirements of industrial automation and equipment connections. Whether providing a stable interface for complex industrial systems or ensuring efficient signal transmission, our solenoid valve connectors have won the trust of customers with their excellent compatibility and durability.
