IP67 Waterproof USB-C Full Function 4K PD Cable

PCM Cable Co., Ltd. is one of the leading ip67 waterproof usb-c full function 4k pd cable manufacturers and suppliers in China. Welcome to wholesale high quality customized products at discount price from our factory. Contact us for quotation and free sample.

Premier Cable PCM-HD-0304 is an IP67 Waterproof USB-C Cable developed for industrial automation, machine vision, industrial computers, and outdoor electronic equipment. It features a waterproof M16 threaded USB-C male connector on one end and a standard straight USB-C male connector on the other.

Unlike basic waterproof Type-C charging cables, PCM-HD-0304 combines 10Gbps high-speed data, DP Alt Mode 4K@60Hz video, and up to 100W power in a single industrial cable assembly.

 ●    The core value of PCM-HD-0304 is the consolidation of data, video, and power into a single USB-C connection. Industrial displays, machine vision terminals, and embedded computing systems can use one interface for high-speed data exchange, 4K display output, and device power.

This three-in-one architecture reduces external cabling and helps simplify compact industrial equipment.



●    The cable supports USB data rates up to 10Gbps, making it suitable for industrial camera images, high-resolution inspection data, external SSDs, data recorders, and test instruments requiring higher bandwidth.

Compared with waterproof Type-C cables limited to USB 2.0 or charging, its 10Gbps capability better supports machine vision and high-speed industrial peripherals.



●    The waterproof end uses an M16 threaded mechanical locking system. After mating with a compatible panel-mount receptacle, the locking ring secures the interface mechanically.

This provides greater retention than a conventional friction-fit USB-C connection, making it suitable for robotics, AGVs, inspection equipment, and industrial cameras exposed to vibration or cable movement.



01



M16 Standard Threaded Lock:

One termination features a heavy-walled M16 metal threaded coupling ring designed for rigid physical interlocking with panel receptacles.

02

Asymmetric Shielded Hybrid Layout:

Configured with an M16 weatherized male on one end and a standard straight USB-C male on the other, facilitating clean interior-to-exterior routing.

03

IP67 Negative-Pressure Seal Rating:

When mated with specific sockets, the interface yields an IP67 rating, completely barring high-pressure liquid washdowns and fine grit.

01.

Machine Vision & Smart Cameras

Ideal for high-speed conveyor inspection, 3D laser profiling, dimensional measurement, and automated defect detection systems. The 10Gbps USB-C link connects industrial cameras, vision controllers, and IPCs for continuous transfer of high-resolution images and point-cloud data, while supporting up to 100W power for compatible devices. M16 locking and IP67 protection improve connection reliability in vibrating, dusty, and wet production environments.

02.

Weatherized Outdoor Signage & Smart Kiosks

Designed for fueling-station multimedia terminals, outdoor digital signage, self-service kiosks, EV charging stations, and traffic information displays. A single USB-C connection can carry high-speed data, DP Alt Mode 4K@60Hz video, and power. When properly locked to a compatible panel receptacle, the IP67 interface and M16 mechanical retention provide enhanced protection against rain, dust, vibration, and frequent maintenance in long-term outdoor installations.

Q1: Can this PCM-HD-0304 cable reliably sustain its rated 10Gbps speed on an industrial floor with heavy EMI noise?

A1: Yes, absolutely. The cable is built strictly to the USB 3.2 Gen 2 framework, featuring matrix-twisted high-frequency signal pairs armored behind dual-layer aluminum foil and high-coverage tinned braid shields. As long as your industrial PC and vision camera native interfaces are 10Gbps rated, the line will smoothly deliver full 10Gbps bandwidth without packet dropping, even inside high-noise automated generator rooms.

Q2: Why do the 1m/2m variants support 100W (5A), while the 3m model drops down to 60W (3A)?

A2: This is dictated by rigorous industrial voltage-drop calculations and USB-IF electrical safety mandates. A 3-meter copper conductor naturally incurs higher DC resistance; forcing a 5A current over this distance would generate unsafe localized heat inside closed industrial panels. To secure your high-value IPC hardware, our 3m version is embedded with a customized E-Marker chip that safely caps power distribution at 60W (3A). Its 10Gbps data piping and 4K@60Hz video fidelity remain fully uncompromised.

Q3: My equipment chassis has a flat smooth pass-through cutout. Can I achieve IP67 waterproofing just by plugging this cable in?

A3: No, the cable alone cannot achieve an IP67 rating on a raw cutout. This cable features an "asymmetric one-end M16 threaded male" assembly. It must be hand-screwed into a standard matching M16 female threaded waterproof panel-mount receptacle (fully stocked and Ready to Ship by Premier Cable). Once tightened, it compresses the integrated rubber O-ring to form an IP67 barrier. The opposite standard straight plug is meant for sheltered interior device hookups inside the cabinet.
