USB C Active Cable USB 3.1 C To C Cable With Screw Locking
This USB C Active Cable USB 3.1 C to C Cable with Screw Locking is designed for industrial and high-performance equipment, providing high-speed, reliable transmission. Built-in signal amplifier chip ensures no signal loss during long-distance transmission and can provide data transmission speeds up to 5Gbps. The USB active repeater cable adopts a 5,000,000 drag chain-rated design and is particularly suitable for machine vision, industrial automation, and environments that require frequent bending.
Specification
| Product name | Active USB-C extension cables USB C to C with screw locking |
| DWG No. | PCM-HD-0124 |
| Connector 1 | USB3.1, type C, male |
| Connector 2 | USB3.1, type C, male, with dual screws |
| Signal amplifier | Built-in signal amplifier chip in both plugs |
| Bend life | 5,000,000 bend cycles |
| Data transmission speed | 5 Gbps |
| Interface standard | USB3.0 |
| Screw | M2, 4.75*43.5mm |
| Shielding | Yes |
| Wire gauge | (26AWG*1P+DAM)*2C+26AWG*1P+26AWG*1C+22AWG*1P+F+AEB |
| Cable diameter | 7mm |
| Cable jacket | PVC, high-flex, drag chain rated |
| Cable length | 7m, 10m, or customized |
Applications
1. Machine Vision & Industrial Inspection
- Connects industrial cameras, visual sensors, and AOI inspection equipment to ensure high-speed image data transmission without delay.
- USB C active cable is suitable for PCB inspection, semiconductor packaging, and automated optical inspection (AOI).
2. Industrial Automation & Robotics
- Stable data connection for dynamic equipment such as robotic arms, collaborative robots (Cobot), and AGV carts.
- USB 3.0 active extension cable is suitable for automobile manufacturing, electronic assembly, and logistics sorting systems.
3. 3D Scanning & Measuring Equipment
- Provides high-speed, low-latency data transmission for 3D scanners, laser rangefinders, and industrial CT.
- Active USB 3.0 cables are suitable for reverse engineering, quality inspection, and digital modeling.
4. Video and image transmission
- The USB active extension cable is suitable for high-resolution image and video transmission, such as industrial monitoring systems, security equipment, etc.
FAQ
Q1: What is an active USB cable?
A1: An active USB cable is a USB cable with a built-in signal amplifier to enhance signal transmission and ensure stable performance over longer transmission distances. Unlike traditional passive USB cables, active USB cables can compensate for signal attenuation, support longer connection distances and higher-speed data transmission, and are typically used in USB 3.0 and higher applications.
Q1: Does an active USB cable need a power supply?
A2: An active USB cable usually does not require an external power supply because it uses the power provided by a USB host device (such as a computer or a USB power adapter) to drive the built-in amplifier circuit. This means that when you connect an active USB cable to a computer or other USB device, it will get the required power through the USB interface without the need for an additional power adapter. But if your USB device requires more power (such as some high-power peripherals), you may need an active USB cable with an external power supply. This is because although an active cable can boost the signal, it may not be able to provide enough power to a device with higher power consumption.
