IX A Key To M12 X-Code Cat6A Ethernet Cable
This IX A Key to M12 X-Code Cat6A Ethernet Cable uses the high-performance Hirose IX40G-A-10S-CV(7.0) plug and is designed for industrial automation, communication and high-bandwidth applications. It supports the Cat6A standard and can provide 10Gbps high-speed data transmission, ensuring reliability and stability in harsh environments. The combination of the IX A Key end and the M12 X-Code Male connector provides high-density connections and excellent anti-interference capabilities, making it ideal for applications such as industrial Ethernet, robot control, and data acquisition systems.
Specifications
| Product name | IX industrial Category 6A Ethernet cable, IX A key to M12 X-code male |
| DWG No. | PCM-HD-0111 |
| Type | Cat6A Ethernet cable, backward compatible with Cat5e / Cat6 |
| Connector 1 | IX A key, HRS IX40G-A-10S-CV(7.0) |
| Connector 2 | M12 connector, X-code, 8-pin, male |
| Cable length | 2m, or customized |
| Transmission rate | Up to 10Gbps |
| Jacket material | TPU (wear-resistant, oil-resistant, and bending-resistant) |
| Shielding | SFTP, 360° full shielding |
| Anti-interference ability | High noise immunity, reducing EMI electromagnetic interference |
| Plug and unplug life | More than 5000 times |
| Contacts | Gold-plated |
| Wire gauge | 26AWG |
| Cable diameter | 6.2mm |
Features
- Compliant with Cat6A standard, supports data transmission rate up to 10Gbps, suitable for high-speed network requirements.
- Adopt HRS IX40G-A-10S-CV(7.0) plug with gold-plated contacts to ensure high reliability and low contact resistance.
- M12 X-Code metal housing, anti-vibration and anti-shock, suitable for mobile devices and robotic arm scenarios
- Double shielding structure (FTP + braided layer) to effectively resist electromagnetic interference (EMI)
- Highly flexible TPU outer sheath, resistant to oil, acid, and alkali.
FAQ
Q1: Does this Cat6A industrial Ethernet cable support PoE (Power over Ethernet)?
A1: This cable supports PoE (Power over Ethernet), which can be used to transmit data and power at the same time. It is suitable for devices that require power, such as industrial cameras, sensors, wired access points, IP cameras, etc.
Q2: What industrial environments is this IX A key to M12 X-code cable suitable for?
Q2: This Cat 6A cable is specially designed for applications such as visual inspection systems, industrial automation, robot control, data acquisition and transmission, and smart manufacturing. Applicable to 10 Gigabit Industrial Ethernet (Profinet, EtherCAT, Ethernet/IP).
